FMS-5K-48

Sunchonglic 48v 5kva Inversor Pure Sine Wave 60A/80A MPPT Hybrid Solar Inverter with AC Charger

FMS-5K-48

Power inverter

Features:

Perfect sine waveform output (Specially designed to start up inductive loads such as refrigerators, motors, pumps, compressors and laser printers as well as electronic loads like TVs, Computers, power tool,etc.)

Built-in 60A or 80A MPPT solar charge controller

Built-in AC charger 10A/20A/30A/40A/50A/60A

Parallel operation with up to 6 units available for FMS 5K

Selectable AC input voltage:170V-280V,90V-280V @50Hz/60Hz Auto Sensing

Cold start functionality(Be able to give output with full load connected without AC mains present)

AC and solar input priority can be manually configurated

Compatible to AC mains input and generator voltage input

Transformerless design provides reliable power conversion in compact size

Equipped with MPPT solar charge controller to maximize and regulate DC power from the solar array for charging the battery bank

Besides, it's worry-free to start up motor-type loads such as refrigeratorrs,motors,pumps, compressors and laser printers as well as electronic loads like TVs, Computers, power tool and battery charger

INQUIRE NOW

SEND ENQUIRY

  X
Submit

Specifications



Product Specification
MODEL FMS-1K-24 FMS-3K-24 FMS-5K-48
Rated Power 1000VA/800W 3000VA/2400W 5000VA/4000W
INPUT
Voltage 230 VAC
Selectable Voltage Range 170-280 VAC (For Personal Computers) 90-280 VAC (For Home Appliances)
Frequency Range 50 Hz/60 Hz (Auto sensing)
OUTPUT
AC Voltage Regulation (Batt.Mode) 230VAC ± 5%
Surge Power 2000VA 6000VA 10000VA
Efficiency(Peak) 90%-93% 93%
Tran sferTime 10 ms (For Pers on al Computers) 20 ms (For Home Appliances)
Waveform Pure sine wave
BATTERY & AC CHARGER
Battery Voltage 24 VDC 24 VDC 48 VDC
Floating Charge Voltage 27VDC 27 VDC 54 VDC
Overcharge Protection 31 VDC 31 VDC 60 VDC
Maximum Charge Current 10A/20A 20A or 30A 10A/20A/30A/40A/50A/60A
SOLAR CHARGER
Maximum PV Array Power 600 W 600W 1500W 3000 W
MPPT Range @ Operating Voltage 30VDC~ 66VDC 30VDC~ 66VDC 30VDC-115VDC 60VDC~ 115VDC
Maximum PV Array Open Circuit Voltage 75 VDC 75 VDC 145 VDC 145VDC
Maximum Charging Current 25A 25A 60A 60A/80A
Maximum Efficiency 98%
Standby Power Consumption 2W
PHYSICAL
Dimension, DxWxH (mm) 128x272x355 140x295x540
Net Weight (kgs) 7.4 8 10 11.05/13.5
OPERATING ENVIRONMENT
Humidity 5% to 95% Relative Humidity(Non-condensing)
Operating Temperature 0° C-55° C
Storage Temperature -15° C-60° C
Product specifications are subject to change without further notice.
MODEL FMS1K-24 FMS3K-24 FMS5K
In verter Power 800W 2400W 4000W
Pmax. generated from solar charger 25Amp 600W 25Amp 600W 60Amp 1500W 60A/80Amp 3000W/4000W
Best Panel Configuration 500Wp (250Wpx2pcs) 500Wp (250Wpx2pcs) 1500Wp (250Wpx6pcs) 3000Wp (250Wpx16pcs)
