FPS-3K-24

Sunchonglic 3000va 24v 220v off grid solar inversor 3kva hybrid inverter with 50A PWM solar controller

FPS-3K-24

Power inverter

Features:

Perfect sine waveform output

Built-in 50A PWM solar charge controller

Built-in AC charger 20A or 30A

Parallel operation with up to 6 units available for FMS 5K

Equipped with PWM solar charge controller to maximize and regulate DC power from the solar array for charging the battery bank

Transformerless design provides reliable power conversion in compact size

Besides, it's worry-free to start up motor-type loads such as refrigeratorrs,motors,pumps, compressors and laser printers as well as electronic loads like TVs, Computers, power tool and battery charger

INQUIRE NOW

SEND ENQUIRY

  X
Submit

Specifications

Product Specification
Model FPS-1K-12 FPS-3K-24 FPS-5K-48
Rated Power                    1000VA/800W 3000VA/2400W 5000VA/4000W
INPUT
Voltage 230 VAC
Selectable Voltage Range 170-280 VAC (For Personal Computers) 90-280 VAC (For Home Appliances)
Freque ncy Range 50 Hz/60 Hz (Auto sensing)
OUTPUT
AC Voltage Regulation (Batt. Mode) 230VAC ± 5%
Surge Power 2000VA 6000VA 10000VA
Efficiency(Peak) 90% 93%
Transfer Time 10 ms (For Personal Computers) 20 ms (For Home Appliances)
Waveform Pure sine wave
BATTERY & AC CHARGER
Battery Voltage 12VDC 24 VDC 48 VDC
Floating Charge Voltage 13.5 VDC 27 VDC 54 VDC
Overcharge Protection 15VDC 30 VDC 60 VDC
Maximum Charge Current 10Aor20A 20Aor30A 10A/20A/30A/40A/50A/60A
SOLAR CHARGER(OPTION)
Charging Current 50A
Maximum PV Array Open Circuit Voltage 40 VDC 80 VDC 105VDC
PV Range @ Operating Voltage 15~18VDC 30~32VDC 60~72VDC
Standby Power Consumption 1 W 2W 2W
PHYSICAL
Dimension, DxWxH (mm) 305*300*110 305*272*100 413*295*120
Net Weight (kgs) 4.5 6.9 9.8
OPERATING ENVIRONMENT
Humidity 5% to 95% Relative Humidity(Non-condensing)
Operating Temperature 0° C-55° C
Storage Temperature -15° C-60° C
